VSI Sand Maker

B Series VSI Sand Maker, commonly known as sand making machine and shaper, is the fourth generation of high-performance sand maker with world-class level, which is the latest development achievements of ZENITH's introduction of German leading experts, and combining with Chinese mining conditions. It is the basis for the development of B Deep-rotor Vertical-shaft Sand Maker and VSI6X Sand Maker.

Materials:Granite, quartz, pebble, limestone, dolomite and basalt etc.

Packaging & Delivery

Wooden box

7-30 Days

  1. Under the maximum throughput of 520t/h, the capacity increases by 30%. The final powder has good grain shape, reasonable gradation and adjustable fineness modulus.
  2. The equipment is light, convenient to operate and use, and has various installation methods. Only minor adjustment can maximize its outstanding performance.
  3. Optimized impact angle and less friction between materials and wear parts directly reduce using costs. Lubrication station completely avoids bearing heating.
  4. Advanced technologies and high-quality materials reduce the failure rate. Shock absorption design makes operation less noisy while the air self-circulation system greatly reduces dust.
Model Soft material Hard material Side and central feeding Fully central feeding Speed (r/min) Power (kw) Overall dimension (mm)
Maximum feeding size (mm) Throughput (t/h)
B-1140 50 45 450-520 225-260 1180-1310 200×2 5100×2690×3200
B-9526 45 40 300-380 150-190 1360-1510 132×2 4560×2450×2780
B-8518 40 35 200-260 100-130 1520-1690 90×2 4140×2280×2425
B-7611 35 30 120-180 60-90 1700-1890 55×2 4100×2250×2258
