SDCY100K9H1-T

10 ton Empty Container Handler
Rated Loading Capacity : 10 t
Wheel Base : 4550 mm
Stacking Height : 9(8'6")

Packaging & Delivery

Wooden box

7-30 Days

SANY container handlers feature a full-electric control diesel engine that truly optimises performance and economy.

The high-torque Volvo diesel engine provides quick, smooth operation.

The CAN-bus throttle control provides a dynamic, but efficient acceleration in optimum working points to minimizing engine wear and stress inside the components.

Advanced Hydraulic Load-sensing Technology delivers the exact power needed.

SANY empty-container handlers are made with the operator in mind.

The machines offer comfort for fatigue-free work,   they are easy to handle,  And the machine durability ensures maximum productivity.

A control system, with advanced HMI display and additional head-up monitor system, GPS remote monitoring system, real-time monitoring with intuitive, ergonomic layout ensure excellent operator comfort and control.



MAIN FEATURES

Capacity w/ ELME588 (single box) == 10 t

Volvo851 Ⅲ,

 DANA HR32000 gearbox

Kessler drive axle D81

Air conditioning as a standard equipment

Fully adjustable comfort seat from Company Grammer

Buddy seat with seat belt

Configurable Joystick for all work functions

Large IFM-HMI high resolution color Display for perfect Monitoring   Additional status display in the driver's field of vision

Load-sensing technology for a highly efficient hydraulic system

Dual variable displacement pump system for highest efficiency (Parker) Load sensing proportional Control-Valve

CAN BUS system for data transfer

CAN BUS diagnostic for main components

Radio pre arrangement

2 liters fire extinguisher

Rotating amber beacon

Sun curtain on the roof
